$60 monthly/$25 weekly
A one-time setup/calibration charge in addition to rental rate noted above may also apply. When this applies, you’ll be informed of the amount of the additional charge at time of order or, if requested, prior to placement of order.
- Lead Shielded Pancake G-M
- For Contamination Survey
INDICATED USE:
Alpha beta gamma survey; sample counting
DETECTOR:
Pancake type halogen quenched G-M
WINDOW:
1.7 ± 0.3 mg/cm² mica
WINDOW AREA:
Active - 15 cm²
Open - 12 cm²
EFFICIENCY(4pi geometry):
Typically 5%-14C; 22%-90Sr/90Y; 19%-99Tc; 32%-32P; 15%-239Pu
SENSITIVITY:
Typically 3300 cpm/mR/hr (137Cs gamma )
ENERGY RESPONSE:
Energy dependent
DEAD TIME:
Typically 80 microseconds
COMPATIBLE INSTRUMENTS:
General purpose survey meters, ratemeters, and scalers
OPERATING VOLTAGE:
900 volts
CONNECTOR:
Series "C" (others available )
CONSTRUCTION:
Lead housing with beige polyurethane enamel paint
TEMPERATURE RANGE:
-4° F(-20° C) to 122° F(50° C)
May be certified for operation from -40° F(-40° C) to 150° F(65° C)
SIZE:
4.5" (11.4 cm)H X 4" (10.2 cm)W X 6.5" (16.5 cm)L
WEIGHT:
5.5 lb (2.5kg)
